Label Printer and AWB OptimX Pro H-310

Discover the efficiency and versatility of Label Printer and AWB OptimX Pro H-310, an essential device for any business that requires fast and high-quality solutions for labels and AWBs. With a printing width of 20-82mm and a printing speed of 152mm/s, this printer is designed to meet your labeling needs efficiently and professionally.

Remarkable Performance

The OptimX Pro H-310 printer not only offers impressive printing speed but also superior print quality, ensuring that every label is clear and easy to read. Whether you need labels for products, AWBs, or other applications, this model proves to be a reliable partner.

Flexible Connectivity

With USB and Bluetooth connectivity options, OptimX Pro H-310 Printer easily integrates into any work environment. This flexibility allows you to use it both in the office and on the go, without compromising performance.

Easy to Use

Its intuitive design makes using this printer a pleasant experience. Regardless of your level of experience, you will be able to set it up quickly and start printing without difficulties. This is an ideal choice for retailers, logistics, and any other field that requires efficient labeling solutions.

Conclusion

The label printer and AWB OptimX Pro H-310 is more than just a printing device; it is a tool that helps you optimize work processes and improve the efficiency of your business. Choose quality and performance with the OptimX Pro H-310 and transform the way you manage labels and AWBs.

Technical Specifications – Model H-310

Printing

• Printing method: Direct thermal

• Printing speed: min. 50.8 mm/s – max. 152 mm/s

• Resolution: 203 dpi (8 dots/mm)

Interface

• USB

• USB + Bluetooth

• USB + WiFi

Memory

• Input buffer: 2 MB

• NV Flash: 4 MB

Fonts

• Font A: 12 × 24

• Font B: 9 × 17

• Chinese fonts: GB18030, BIG5 (24 × 24 dots)

• User-defined fonts: Supported

Graphics

• Character sizes: Font 0 ~ Font 8

• Graphic processing: support for BMP / PCX / BAS files

Barcodes

• 1D:
  CODE128 / 128M / EAN128 / CODE39 / 39C / 39S / CODE93 / EAN13 / EAN13+2 / EAN13+5 /
  EAN8 / EAN8+2 / EAN8+5 / 25 / 25C / CODABAR / POSTNET / UPC-A / UPCA+2 / UPCA+5 /
  UPC-E / UPCE+2 / UPCE+5 / CPOST / MSI / MSIC / PLESSEY / ITF14 / EAN14

• 2D: PDF417 / QR Code / Data Matrix

Sensors

• Print head temperature sensor (sensitive thermal resistance)

• Paper presence detection (photoelectric sensor)

Power Supply

• Input: AC 100–240 V, 50/60 Hz

• Output: DC 24 V / 2.5 A

Paper

• Type: Thermal paper for receipts / thermal labels

• Width: 20 – 80 mm

• Thickness: 0.06 – 0.19 mm

• Inner diameter of roll: 25 – 38 mm

• Outer diameter of roll: max. 90 mm

• Paper cutting: Tear off (manual tearing)

Operating Conditions

• Operating: 5°C – 45°C, humidity 20% – 80% RH

• Storage: -40°C – 55°C, ≤93% RH (at 40°C)

Physical Characteristics

• Dimensions: 184(L) × 144(W) × 131(H) mm

• Net weight: 1.55 kg

• Gross weight: 1.8 kg

Reliability

• Print head lifespan: 50 km

Included Accessories

• USB cable

• Power adapter

• Power cable

• Manual

• CD

• Roller

• Paper separator

Packaging

• Individual box: 28.6 × 16.4 × 16 cm (1 unit / box)

Software Compatibility

• Emulation: TSPL (label mode) / ESC/POS (receipt mode)

• Supported operating systems:

  • Windows XP, 7, 8, 10

  • MacOS

  • Linux

• SDK: Android / iOS
